After sharing experienced to use Smartphone with OS Windows Phone, now i'd shared
experienced using Smartphone with OS Android 5.0.2 that is Hisense Andromax i46D1G
or more known with Smartfren Andromax R with spesification :
[
- Operating System (OS): Android 5.2 ( Lollipop )
- Processor: Snapdragon 410 Quad Core 1.2 Ghz Cortex A53 Processor
- Memory: 1GB RAM + 8 GB ROM
- Storage: MicroSD Card up to 32 GB
- Display: 5 inches Screen HD iPS OGS with Dragon Trail Glass (1080x720)
- Camera: 8 MP AF Dual Flash (Rear), 5 MP LED Flash (Front)
- Connectivity: 4G-LTE/EVDO/GSM, WiFi 802.11/B/G/N, Bluetooth v4.0, microUSB v2.0
For anyone who own Smartphone Android certain never be made confused when
transfering data from handphone to PC or to other handphone because its easy
to send file using mass storage or bluetooth devices ???
Many Android OEM offer it way to to open bootloader or more known with
Unlocking and Rooting who make confused several and specially for the
beginner or commonnly Android users to what must be done Unlocking and
Rooting or not ???
Rooting is the process of allowing users of smartphones, tablets and other
devices running the Android mobile operating system to attain privileged
control (known as root access) over various Android subsystems. As Android
uses the Linux kernel, rooting an Android device gives similar access to
administrative (superuser) permissions as on Linux or any other Unix-like
operating system such as FreeBSD or OS X.
Root access is sometimes compared to jailbreaking devices running the Apple
iOS operating system. However, these are different concepts: Jailbreaking is
the bypass of several types of Apple prohibitions for the end user, including
modifying the operating system (enforced by a "locked bootloader"), installing
non-officially approved applications via sideloading, and granting the user
elevated administration-level privileges (rooting). Only a minority of Android
devices lock their bootloaders, and many vendors such as HTC, Sony, Asus and
Google explicitly provide the ability to unlock devices, and even replace the
operating system entirely. Similarly, the ability to sideload applications is
typically permissible on Android devices without root permissions. Thus, it is
primarily the third aspect of iOS jailbreaking (giving users administrative
privileges) that most directly correlates to Android rooting.
Advantages
-
Support for themes, allowing everything to be visually changed from the
color of the battery icon, to the boot animation that appears while the
device is booting, and more.
-
Full control of the kernel, which, for example, allows overclocking and
underclocking the CPU and GPU.
-
Full application control, including the ability to backup, restore, or
batch edit applications, or to remove bloatware that comes pre-installed
on many phone.
-
Custom automated system-level processes through the use of third-party
applications.
-
Ability to install a custom firmware (also known as a custom ROM) that
allows additional levels of control on a rooted device.
Rooting Varieties
The process of rooting varies widely by device, but usually includes exploiting
one or more security bugs in the firmware of (i.e., in the version of the Android
OS installed on) the device. Once an exploit is discovered, a custom recovery
image can be flashed which will skip the digital signature check of firmware
updates. Then a modified firmware update can be installed which typically
includes the utilities needed to run apps as root. For example, the su binary
can be copied to a location in the current process' PATH (e.g., /system/xbin/)
and granted executable permissions with the chmod command. A third-party s
upervisor application, like Superuser or SuperSU, can then regulate and log
elevated permission requests from other applications. Many guides, tutorials,
and automatic processes exist for popular Android devices facilitating a fast
and easy rooting process.
Conclusion
For any user that do not need administration-level privileges and own financial
excess do not need it Unlocking and Rooting also not suggested by the most of
Smartphone Android vendor.
.: iMPORTANT NOTiCES
[Show] !!! :.
-
Sorry for my bad english, i will only use the words i already know for this article.
To all of visitor i'd really sorry for any inconvenience !!!
-
Testing new roms, kernels or other tweaks is, at least in my opinion,
part of the whole Android experience. But sometimes things go wrong.
First of all: Don’t panic! In contrast to iOS or Windows Phones,
Android is a rather open operating system which makes fixing a soft-
bricked device sometimes really easy.
You can revive your device as long as it is only soft-bricked! But
beware, depending on your device it can be quite tricky to fix a soft-
brick. A rule of thumb is that every device with an unlockable boot
loader and accessible stock files.
In most cases something went wrong while flashing something like a
custom ROM, camera mod or app in your custom recovery mode. Because
of this, your device is not booting anymore (the so-called bootloop)
or is constantly crashing. The basic solution to this problem is
flashing a clean & working version of Android to your device. There
are different ways for doing this, but most of the time you’ll restore
a backup, flash a custom ROM or stock images to your device.
(By Philipp Greitsch).
-
Avoiding stuck in bootloop, softbrick/hardbrik without USB Debugging issues
for Andromax R (HS8916QC) or any Android Devices that lack of options in Stok
Recovery ROM, i'd suggested to used Custom TWRP (recommended) or CWM Recovery
that allready rooted and support for USB Debugging functionality, which means
ADB commands work while your Android device is recovery mode. !!!
-
I have some references for you. these groups its fulfilling to reviews
about Andromax R (HS8916QC). Starting from ROOT, ROM, Game, even Tweaks
that given by the developer. but beware, you must carefully to join with
some group that exist in Facebook specially. Because recently a lot of
group with the same title discuss a certain devices but in the inside also
a lot of spam or rubbish. In this occasion i found several group and related
articles that the most relevant at the end (bottom) of the pages.
-
Please make a backup of your device before installing or updating ROM !!!
.: TODO :.
-
Repair Corrupt, Bad or Incorrect MEID/ESN Number.
Any idea how to create or edit a new (loss) Meid/Imei and others iD.
Your ideas or suggestion will be appreciated :)
Thanks.
.: [EXPERiMENTAL] Log Files (March 20, 2016)
[Show] :.
.: TECHNiCAL DiFFiCULTiES iSSUES (SOLVED) :.
.: To be continue, so stay tune !!! :.
.: [EXPERiMENTAL] Log Files (March 15, 2016)
[Show] :.
.: TECHNiCAL DiFFiCULTiES iSSUES (SOLVED) :.
My Andromax R (HS8916QC) Finally Come Back To Life (Unbricked) !!!
Special thanks to su91art0.st - Kaskuser.
.: How To Revive Andromax R Back To Life (Unbrick) !!! :.
Disclaimer: Do with your Own Risk (DWYOR)
Important Note:
In this case MEiD/ESN number allready loss, corrupt, bad or incorrect (zeroed out)?,
so if devices still had MEiD/ESN number please refer to the original thread from
Raw Image Smartfren Andromax R
I46D1G_L1074L.6.05.02.ID11_Official by
su91art0.st !!!
Step 1: Unbrick Qualcomm HS-USB QDLoader 9008 to 9006
-
Download and Install QPST 2.7 build 429 and driver Qualcomm WHQL
-
Download and extract 9008 to 9006 Andromax R file.
-
Connect your Andromax R to PC or laptop (press vol. up + power button until
detected as “Qualcomm HS-USB QDLoader 9008” and then run QPST eMMC Software Download.
-
Insert all the necessary file needed :
- Sahara Xml File: \i46d1g.v1\sahara.xml
- Flash Programmer file name: MPRG8916.mbn
- Boot Image: 8916_msimage.mbn
- Uncheck Program MMC Device
- Check Search Path 2, Browse to folder i46d1g.v1
- Clik Download. wait until detected as “Qualcomm HS-USB QDLoader 9006” and then close QPST eMMC Software Download.
-
Done Unbrick Qualcomm HS-USB QDLoader 9008 to 9006.
-
Attached File:
Step1_Unbrick_9008_to_9006_Snap8.scrshot.7z
Size : 1884 kb | 1.83 MB (1,929,918 bytes)
MD5 : 644F6FBB0ED21985C5EC43B6118E47CA
SHA1 : FD8451456E4E0EA1600CCB13A33CC3CED7643DCE
Step 2: Backup Qualcomm MMC Storage (OPTiONAL)
-
Download HDD Raw Copy Tool, it is a free tool that can copy your “backup.img” to your Mobile’s eMMC sector per sector.
-
open “HDD Raw Copy Tool”, SOURCE Device Choose “Qualcomm MMC Storage 1.00 (7818.18MB)” and click “Continue”
-
TARGET Device Choose “Double -click to open file”, browse backup location and enter the backup name then click “Continue”
-
Wait until current task progress 100% completed.
-
Attached File:
Step2_Backup_Image_HDD_Raw_Copy_Snap8.scrshot.7z
Size : 367 kb | 367 KB (376,792 bytes)
MD5 : CAAD90EAAE12030BEE1C102A75BB7D52
SHA1 : E399C676BDCE88BC221761076F98FAD4A47EF45E
Step 3: Check eMMC “backup.img” (External Link)
Step 4: Restored (Flashing) eMMC “backup.img” (CAREFULLY)
-
Download and extract i46D1G_L1074L.6.05.02.iD11_Official.rar.
Size : 933792 kb | 911 MB (956,203,370 bytes)
MD5 : 02FF8E89C404B862C1DAEC33E991984F
SHA1 : E7513C3DF2A71635CF1F325F82B2DC7D1DDE3B60
-
open “HDD Raw Copy Tool”, SOURCE Device Choose “Double -click to open file”, browse to extracted “i46D1G_L1074L.6.05.02.iD11_Official.img” location then click “Continue”
-
TARGET Device Choose “Qualcomm MMC Storage 1.00 (7818.18MB)” and click “Continue”
-
Check every things and click “START”.
Hints:
* Are you absolutely sure you want to proceed? [Yes]
* Do you want to format it? [Cancel]
-
Wait until current task progress 100% completed.
-
Attached File:
Step4_Restore_Image_HDD_Raw_Copy_Snap8.scrshot.7z
Size : 366 kb | 366 KB (375,550 bytes)
MD5 : 25251CD6127AAB7BBDFF93D7608D6F1D
SHA1 : 724FDA35EBCBCFE4BF3EFB100226EF2ADE2081D8
There you are, your Andromax R will finally come back to life. Let me know if this process helped you
by commenting on the commentary column at the bottom of the pages.
Credit:
.:
[Official Lounge] Smartfren Andromax R, CDMA goes 4G LTE :.
.: [EXPERiMENTAL] Log Files (March 9, 2016)
[Show] :.
TECHNiCAL DiFFiCULTiES iSSUES (CASES)
-
I was a noobs and newbies user for android smartphone, I bought
Andromax R (i46D1G) with OS Android 5.02 and testing to flashing
flashing Stok Recovery ROM with Custom TWRP Recovery the rooting
using KingRoot and Flashing with Custom Boot ROM, it work fine.
-
Then i'd try to Rollback to Stock Boot and Recovery ROM, removing
or flashing TWRP Recovery ROM with Stock Recovery ROM (i'm not
aware that Stock Recovery ROM is diffrent than commonly Stock ROM
Recovery Mode), anyway it work fine. But sometimes things go
wrong when restored or flashing Stock Boot ROM using Rashr - Flash
Tool 2.3.10 (APK) as "kernel" and get stuck in Bootloop without
"USB Debugging" functionality to reset the "Bootloader Unlocked".
-
.: FYi: Stock Boot and Recovery ROM Andromax R (i46D1G) :.
* Software Version: i46D1G_L1074L.6.04.02.iD11
» File Name: fastboot_i46D1G.7z ==> Stock Boot ROM
» Size: 9.79 MiB (10,267,017 bytes)
» SHA1: F521597F71E543AFEEB70D519DF0C57C09582FD0
» Share Link: Mega Cloud
» File Name: recovery_i46D1G.7z ==> Stock Recovery ROM
» Size: 8.01 MiB (8,402,638 bytes)
» SHA1: 8ECCC2F3080858AB6AF20C28B63DA88635191C05
» Share Link: Mega Cloud
KNOWN BUG
-
Can't turn on "USB Debugging" functionality to do a recovery because
"Bootloader Locked" and "Stock ROM Recovery Mode" only had two options?
------------------------------------
» reboot system now
» wipe data/factory reset
------------------------------------
"Commonly Stock ROM Recovery Mode" has options...
------------------------------------
» reboot system now
» apply update from ADB
» wipe data/factory reset
» wipe cache partition
------------------------------------
-
Recovery via Android Debug Bridge (ADB) and/or Fastboot Commands ???
As I'm sure you're aware, ADB does not work with/for Fastboot/Bootloader mode...
» Root permissions and ADB Shell is not present.
» File system restricted and denied access.
» List of devices attached
[Show Screeenshot]
-
Recovery via TF card (MicroSD Card) Failed...
» Could not read signature file!
» Read Signature or Flag File error!
.: FYi: Andromax R (i46D1G) ROM and Debug Files are Used :.
» ROM Files: http://pasted.co/fc3b831f
» Debug Files: http://pasted.co/ff13b4f0
-
Computer does not recognise the devices in Normal Mode (Bootloop) except Test Mode
by press Vol.up + Power button and plug-in the USB Cable until recognised ???
.: [EXPERiMENTAL] Log Files (February 26, 2016)
[Show] :.
KNOWN BUG
[Show Screeenshot]
-
System NOT Updated (current version:
L1074L.6.04.02.ID11 can be upgraded to
L1074L.6.05.02.ID11).
-
Remove Custom ROM Boot.img and Remove Root Andromax R (i46D1G).
-
Superuser Binary Files: Installed
Result: -rwxr-xr-x root root 159472 2016-01-29 01:14 su
Version: 3.54:kinguser_su
Analysis:
» Root user ownership is present and stuid attribute is not present.
» File system permissions restricted and denied access.
SOLVED:
-
Rollback stock ROM Recovery.img Andromax R (i46D1G)
or Remove TWRP Recovery.img
[Show Screeenshot]
HOW-TO:
Disclaimer: DWYOR (Do With Your Own Risk)
Required:
» Stock ROM Recovery.img (i46D1G)
- File Name: recovery_i46D1G.7z
- Software Version: i46D1G_L1074L.6.04.02.iD11
- Size: 8.01 MiB (8,402,638 bytes)
- SHA1: 8ECCC2F3080858AB6AF20C28B63DA88635191C05
- Share Link:
Mega Cloud
» Terminal Emulator APK (Material Terminal v2.03)
-
install Terminal Emulator APK then enter the code sequentially :
su --> [enter]
dd if=/sdcard/i46D1G_recovery.img of=/dev/block/mmcblk0p29
--> [enter, wait until completed]
reboot recovery --> [enter]
Note:
if system go bootloop, turn off by pull out
the battery (this was the most tedious part for a crappy back cover).
Then pull back in the battery turn on by press button power + volume
down to enter Stock ROM Recovery Mode.
-
After reboot on screen will look like this :
product: i46D1G
System status: rooted!
Long press power key to continue ...
-
Recovery Mode Stock ROM Andromax R (i46D1G) will look as follow : :
Android system recovery
LRX22G release-keys
Volume up/down to move highlight;
enter buton to select.
reboot system now >
wipe data/factory reset >
Note:
After Factory Data Reseted succesfully then
reboot the system.
- Now stock ROM Recovery Andromax R (i46D1G)
should be installed or TWRP Recovery removed successfuly.
- Hope that help :)
-
Remove or Uninstall Root Permission
[Show Screeenshot]
HOW-TO:
» Disclaimer: DWYOR (Do With Your Own Risk)
» Required: KingRoot APK
-
Install the latest KingRoot APK and open it.
* Recommended to read KingRoot Instructions
first : Menu > About app > Instructions.
-
Go to Menu > General Setting > Uninstall KingRoot
--> Continue, then wait until removing root permission completed
(system may be rebooted during process of removing removing root
permission).
- After all process successfully completed,
now system should be unrooted.
Note:
FYi: if the devices rooted by custom ROM, this
is not permanent the system will back to rooted! whether is advantages or
disadvantages may be differ for some user ?
- Hope that help :)
Bagi Sobat(2x) yang ingin & berbagi ilmu tentang
"[EXPERiMENTAL] Andromax R
(i46D1G)"
dipersilahkan untuk melengkapi dengan menuliskannya
pada kolom komentar di bawah... :)
Jazakumullohu Khouiron Katsiron
Hope That Help / Semoga Bermanfaat / Muga Aya Mangpaatna !
Thanks (Terima Kasih/Hatur Nuhun) for Stopping By !
FYi:
We are still experiencing technical (hardware outdated) difficulties issues...
... We are sorry to all of visitor for any inconvenience !!!
We're Highly Appreciate Any Support & Suggestion,
To Keep This Blog Alive !
